Blue Sea 8120 – 5 Position 12V Panel w/Dual USB12V Socket [8120]

Original price was: $434.39.Current price is: $286.23.

Sale!

68 in stock

SKU: MM-90049 Category:
Share

8120 – 5 Position 12V Panel w/Dual USB & 12V Socket

Part of the Blue Sea Systems Battery Management Panels.  Distribute current from a high amperage source to lower amperage circuits.

Features:

  • ON-indicating LEDs
    • Backlit label positions
  • All positive, negative, and grounding buses installed, fully pre-wired

Specifications:

  • Positions – Five (5)
  • Nominal Voltage – 12V DC
  • Maximum Amperage – 50A
  • Circuit Breaker Type – Magnetic Hydraulic – Trip Free
  • USB Output – 12/24V Dual USB
  • Socket Output – 12V Dash socket
  • Dimensions (H x W x D) – 7.5″ x 5.25″ x 2.5″ (191 x 133 x 64mm)

In the Box:

  • 8120 Panel
  • Instruction Manual

*Sold as an Individual

Specifications:

  • AC/DC: DC
  • Max Breaker Quantity: 5
  • Voltage: 12
  • Box Dimensions: 5″H x 7″W x 12″L WT: 1.95 lbs
  • UPC: 632085081201

Owner’s Manual (pdf)
